MX4x4DVI-DL
User’s Manual
Page 15 / 43
Loading a Preset in AUTOTAKE mode
1. Press and release LOAD PRESET button.
2. Press and release the desired source (memory address) button (source 1 to
4). Now the selected preset is loaded.
Info Loading a preset always modifies all output states.
VIEW current state
User can check the current switching status on the front panel using front panel
buttons. View mode is slightly different in TAKE or AUTOTAKE modes because of
different switching philosopy of the two modes.
Info View mode does not mean, that the router has to be switched in different mode,
viewing and switching can be done after each other, without pressing any special
button.
View current state in TAKE mode
If the router is in TAKE mode, user can verify both input and output connections. In
TAKE mode no accidental change can be done unless TAKE button is pressed.
Press and release a source button. Now the selected source button and all
destination buttons will light up which are currently connected to the selected
source. This informative display will remain for 5 seconds, then turns all buttons
unlit.
If all source and destination and TAKE buttons are unlit (the unit is in TAKE mode,
and no input was selected in last 5 seconds), press and release a destination
button to see its current state. Now the source button which is connected to the
selected destination will light up. If no source button is lighting, the selected
destination is in muted state. Pressing another destination button, there can be
seen the last pressed state of destination.
View current state in AUTOTAKE mode
In AUTOTAKE mode only states of destination can be viewed.
Press and release the required destination button. Now the source button which is
connected to the selected destination will light up. If no source button is lighting,
the selected destination is in muted state. Pressing another destination button,
there can be seen the last pressed current state of destination.
