MMX4x2 series – User's Manual 90
Command and Response #portstatus
ç
æ <out1_state>;<out2_state>
state, the next 2-byte-long HEX code shows the current state of the output ports. #portstatus
Parameters
The structure of the response <out#_state> is the same as the <in#_state> described in the previous section.
Example
ç
æ
M 0 0 B F
Unlocked,
Muted
0 0 0 0 0 0 0 0 1 0 1 1 1 1 1 1
Reserved Reserved Reserved Reserved
No emb.
audio
Encrypted
Signal
presents
Connected
Command and Response #crosspoint #switch
ç
æ <in>;<in>
Example
ç
æ
I1 input port is connected to the O1 output port, I3 input port is connected to the O2 output port.
Switching Video Input
Command and Response
ç <in>:<out>)
æ
Example 1
ç
æ
Example 2
ç
æ
Command and Response #autoselect
ç
æ <out1_set>;<out2_set>;<out3_set>
The response shows the settings of each output one by one. The structure of the response is the following:
<out#_set> = <state><mode>
Parameters
Parameter Parameter description
<state> The state of the
autoselect
E
The autoselect is enabled
D
The autoselect is disabled
<mode> The mode of the
autoselect
F
First
P
Priority detect mode: always the highest priority active video
input will be selected.
L
Last detect mode: always the last attached input is
switched to the output automatically.
Example
ç
æ
EL: the Autoselect is Enabled on the output 1, selected mode is Last detect.
DP: the Autoselect is Disabled on output 2 and output 3.
INFO: For more information about the Autoselect feature, see The Autoselect Feature section.
