23
If required, the upper basket should be adjusted to create more space for large plates on the
upper or lower basket.
MAX Ø240mm
MAX Ø250mm
MAX Ø190mm
MAX Ø300mm
Loading the Upper and Lower Basket for 13 Place Settings (according to EN
50242)
For optimum loading of crockery in the upper and lower basket, please refer to the below table
and image.
Upper basket
Lower basket
3
2
2
4
5
2
3
2
2
3
1
6
1
7
8
9 9
87 711
10
Lower Basket
We recommend that large items and the most dicult to clean items are placed in the lower
basket, such as plates, serving platters, saucepans, serving bowls, pots, pans, lids etc. We
recommend placing serving dishes and lids at the side of the basket to avoid blocking the
rotation of the spray arms.
Hinged Spikes
The spikes are used for holding plates and a platter.
LID60W20_IB_RC_Final210603.indd 23LID60W20_IB_RC_Final210603.indd 23 3/6/2021 5:42 PM3/6/2021 5:42 PM
