Logitech Harmony 525 User Manual

17
Whether you get a new device or want to change the behavior of some buttons, you may need to
make changes to your Harmony 525 setup. The following sections provide you with the information
to help you with these tasks.
Changing your setup
To add or change a device in your Harmony 525 set up, use the Harmony Remote
Software and select the Devices tab.
To add a device, click • Add Device.
To remove a device, click the • icon for the device you want to remove.
To modify the settings for a device, press the • Settings button for the device you
want to modify.
In the Harmony Remote Software, select the Activities tab.
To add an Activity, click • Add Activity.
To remove an Activity, click the • icon for the Activity you want to remove.
To modify the settings for an Activity, press the • Settings button for the Activity you
want to modify.
Adding and changing your devices
Adding and changing your Activities
If you delete a device, be sure to update your Activities!
Renaming an Activity
In some cases, you may want to rename an Activity. You can rename any Activity
using the Harmony Remote Software.
To rename an Activity, go to the Harmony Remote Software:
Select the 1. Activities tab.
In the Activity you want to rename, click 2. Settings.
Select 3. Rename <current Activity name>.

Logitech Harmony 525 Specifications

General

LCD Size	1.5" Diagonal
LCD Resolution	96 x 64
LCD Screen	Monochrome
Power Source	4 x AAA batteries
Power Type	Alkaline
Brands Supported	5, 000+
Devices Supported	225, 000+
Maximum number of devices per account	10
Backlit keypad	Yes
Backlight Color	Blue
IR Learning	Yes (Up to 250 Khz)
IR Transmit	15.625 kHz to 500 kHz
Learning Capabilities	Any IR Device
IR Transmitters	2
IR Transmission Range	Up to 30ft
Warranty	2 Years
Memory Type	Flash
Memory Amount	512 KB
Supported Platforms	Windows 2000/XP/Vista MAC OS X 10.3 +

Weight and Dimensions

Weight	5.4 oz (with battery installed)
Dimensions	1.9” x 8.0”
