3 -14
(1) PTO switch
To operate the electro-hydraulic PTO, comply
with the instructions as below.
1. Sit in driver’s seat correctly and start engine.
2. Place the PTO select lever to the desired
position..
3. Put the PTO switch to “ON” to rotate the PTO
shaft.
4. To stop the PTO temporarily, push down the
PTO switch and then the switch will
automatically return to “OFF” position.
5. Before shifting the PTO select lever, make
sure to push down the PTO switch in “OFF”
position.
ON : Push and Turn
OFF : Push
PTO switch
HST
OFF
ON
▶ To start the engine, the PTO switch must be placed in “OFF” position.
▶ Before connecting or checking the implement, place PTO switch in “OFF” position.
▶ The PTO shaft rotates even if the tractor moves backward. Pay attention to the
surroundings to prevent an accident.
▶ Do not engage the PTO clutch with the engine running at high speed. Sudden
engagement can cause damage to the implement and PTO clutch. Engage the
PTO at low idle rpm, and then raise the engine speed up.
Warning
