MAAX Utile User Manual

21
Insert the washers (8) in the shelf support cap (9). Align
and insert the shelf support caps (9) with the holes of
the glass and the holes of the shelf brackets (6). Screw
from the bottom of the shelf with the # 10 x ½'' screws
(10) and tighten by hand with the Allen key (11).
9
10
6
8
11
7
10
STEP Glass shelf installation (cont'd)
Align oblong holes
10.3
Check me!
Do not overtight the support cap (9)
For the wall nish you can install install your nishing
material on top of the ange or on the wall edge as shown.
11
STEP Wall nish
Check me!
Finishing
material
Finishing
material
