DESCRIPTION
■ General construction
The transmission case, Clutch, Clutch housing, Engine and Front Axle Support are bolted together to
form a rigid unit
■ Front Axle & Wheels
The 4WD front axle is a center-pivot, reverse Eliot type. The front wheel drive mechanism is
incorporated as a part of the axle.
The front wheel drive power is taken off the rear transmission and transmitted to the differential in
the front axle where the power is divided into right and left and to the respective final cases.
In the final cases, the transmitted revolution is reduced by the level gears to drive the front wheel.
The 4WD mechanism with level gears provides wider steering and greater durability.
■ Engine
The tractors are fitted with vertical, Water-cooled 4-cycle and spherical chamber type Daedong
ENGINES(4A220-DY)
■ Clutch and Transmission
A single plate dry clutch(10.24″diameter) is used on these tractors. Tractor with IPTO(Independent
Power Take Off) are fitted with hydraulic Clutch Assy. The transmission Gear box has sixteen
forward & sixteen reverse speeds of 4510 with high-low selector lever, Presently, Mahindra Tractors
are fitted with partial synchro mesh type gears.
■ Brakes
Mahindra tractors are provided with independent disc brakes operated by two road travel. A foot
brake lever is fitted for parking.
■ Rear axle & Wheels
This is mounted on ball bearings and is enclosed in removable housing which are bolted to the
transmission case. The rim & Disc fitted with Rear tires are bolted to the outer flange of Rear Axle.
■ Hydraulic system & Linkages.
Mahindra Tractors are fitted with Live (i.e. system is in operation even when clutch is disengaged.)
independent, very touch of hydraulic System. Three point Linkages can be used for category 1 type
of implements.
