Makita AF506 User Manual

5 ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: AF506
Air pressure 0.49 - 0.83 MPa (4.9 - 8.3 bar)
Nail gauge 18 Ga.
Nail length 15 mm - 50 mm
Nail capacity 100 pcs.
Minimum hose diameter 6.5 mm
Pneumatic tool oil ISO VG32 or equivalent
Dimensions (L x W x H) 250 mm x 70 mm x 256 mm
Net weight 1.3 kg
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
without notice.
• Specicationsmaydifferfromcountrytocountry.
Symbols
Thefollowingsshowthesymbolsusedfortheequipment.Be
surethatyouunderstandtheirmeaningbeforeuse.
Read instruction manual.
Wearsafetyglasses.
Wear ear protection.
Donotuseonscaffoldings,ladders.
Intended use
Thetoolisintendedforfasteningoninteriorworkand
furniturework.
Thetoolisforhigh-volumeprofessionalapplicationonly.Do
notuseitforanyotherpurpose.Itisnotdesignedtodrive
fastenersonahardsurfacelikesteelandconcrete.
Noise
The typical A-weighted noise level determined accord-
ing to ISO11148-13(EN12549):
Sound pressure level (L
pA
):99dB(A)
Sound power level (L
WA
):109dB(A)
Uncertainty(K):1.5dB(A)
NOTE: The declared noise emission value(s) has
been measured in accordance with a standard test
methodandmaybeusedforcomparingonetoolwith
another.
NOTE: The declared noise emission value(s)
mayalsobeusedinapreliminaryassessmentof
exposure.
WARNING: Wear ear protection.
WARNING: The noise emission during actual
use of the power tool can differ from the declared
value(s) depending on the ways in which the
tool is used especially what kind of workpiece is
processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).
Vibration
The vibration total value determined according to
ISO11148-13(ISO8662-11):
Vibration emission (a
h
) : 7.6 m/s
2
Uncertainty (K) : 1.5 m/s
2
NOTE: The declared vibration total value(s) has been
measured in accordance with a standard test method
andmaybeusedforcomparingonetoolwithanother.
NOTE: The declared vibration total value(s) may also
beusedinapreliminaryassessmentofexposure.
WARNING: The vibration emission during
actual use of the power tool can differ from the
declared value(s) depending on the ways in which
the tool is used especially what kind of workpiece
is processed.
WARNING: Be sure to identify safety mea-
sures to protect the operator that are based on an
estimation of exposure in the actual conditions of
use (taking account of all parts of the operating
cycle such as the times when the tool is switched
off and when it is running idle in addition to the
trigger time).

Makita AF506 Specifications

General

Soft grip	Yes
Product type	Nailer
Product color	Black, Blue, Silver
Magazine capacity	100
Nail length (max)	50 mm
Nail length (min)	15 mm
Hose inner diameter	1/4 \
Maximum operating pressure	8.27 bar
Minimum operating pressure	4.82 bar
Power source	Pneumatic

Weight and Dimensions

Depth	70 mm
Width	250 mm
Height	256 mm
Weight	1300 g

Summary

Specifications

Intended Use

Noise Information

Details A-weighted noise levels and measurement standards.

Vibration Information

Safety Warnings

Pneumatic Nailer/Stapler Safety Warnings

Specific safety advice for pneumatic nailers and staplers.

General Safety

General safety precautions for operating the tool.

Projectile Hazards

Information on hazards related to fasteners being ejected.

Functional Description

Adjusting Depth of Nailing

Operation

Checking Proper Action Before Operation

Driving Nails

How to properly drive nails using the tool.

Removing Jammed Nails

Maintenance
