9 ENGLISH
Thus,forexample,ifnailingtakesplaceatarateof
approximately 60 times per minute at a compression
of0.74MPa(7.4bar),acompressorwithanairoutput
over 55 liters/minute is required.
Pressure regulators must be used to limit air pressure to
theratedpressureofthetoolwhereairsupplypressure
exceeds the tool's rated pressure. Failure to do so may
resultinseriousinjurytotooloperatororpersonsinthe
vicinity.
Selecting air hose
CAUTION: Low air output of the compressor,
or a long or smaller diameter air hose in relation
to the nailing frequency may cause a decrease in
the driving capability of the tool.
►Fig.2
Use an air hose as large and as short as possible to
assurecontinuous,efcientnailingoperation.
Withanairpressureof0.49MPa(4.9bar),anairhose
withaninternaldiameterofover6.5mmandalength
oflessthan20misrecommendedwhentheinterval
between each nailing is 0.5 seconds.
Air supply hoses shall have a minimum working pres-
sureratingof1.03MPa(10.3bar)or150percentofthe
maximum pressure produced in the system whichever
is higher.
Lubrication
►Fig.3
Toinsuremaximumperformance,installanairset(oiler,
regulator,airlter)ascloseaspossibletothetool.
Adjusttheoilersothatonedropofoilwillbeprovided
forevery50nails.
Whenanairsetisnotused,oilthetoolwithpneumatic
tool oil by placing 2 (two) or 3 (three) drops into the air
tting.Thisshouldbedonebeforeandafteruse.
Forproperlubrication,thetoolmustberedacoupleof
timesafterpneumatictooloilisintroduced.
►Fig.4: 1. Pneumatic tool oil
FUNCTIONAL
DESCRIPTION
CAUTION: Always disconnect the hose
before adjusting or checking function on the tool.
Adjusting depth of nailing
►Fig.5: 1.Adjuster
Toadjustthedepthofnailing,turntheadjuster.
Thedepthofnailingisthedeepestwhentheadjuster
isturnedfullyintheAdirectionshowninthegure.It
willbecomeshallowerastheadjusteristurnedintheB
direction.
Ifnailscannotbedrivendeepenoughevenwhenthe
adjusteristurnedfullyintheAdirection,increasethe
air pressure.
Ifnailsaredriventoodeepevenwhentheadjusteris
turnedfullyintheBdirection,decreasetheairpressure.
Generallyspeaking,thetoolservicelifewillbelonger
when the tool is used with lower air pressure and the
adjustersettodeeperdepthofnaildriving.
Hook
CAUTION: Never hook the tool at high loca-
tion or on potentially unstable surface.
CAUTION: Do not hang the hook from the
waist belt.Ifthenaileraccidentallydrops,itmay
resultinmisringandpersonalinjuries.
►Fig.6
►Fig.7: 1. Hook
Thehookisconvenientforhangingthetooltemporarily.
Air duster
CAUTION: Do not aim the ejection port of the
air duster to someone. Also, keep your hands and
foot away from the ejection port.Iftheairduster
buttonisaccidentallypushed,itmaycauseaper-
sonalinjury.
CAUTION: Always check your surroundings
before using the air duster.Blowndustorobjects
may hit someone.
CAUTION: Do not connect or disconnect the
air hose while pushing the air duster button.
The air supplied to the tool can also be used as an air
duster.Youcancleantheworkareabypressingthe
button on the grip end.
►Fig.8: 1.Button
NOTICE:Afterusingtheairduster,thedrivingforce
ofthetoolwilltemporarilydecline.Waituntiltheair
pressure recovers in this case.
NOTICE:Performatestblowifyouusetheair
dusterimmediatelyaftertheoilwasapplied.Theoil
may be sprayed with the air.

Makita AF506 Specifications

General

Soft grip	Yes
Product type	Nailer
Product color	Black, Blue, Silver
Magazine capacity	100
Nail length (max)	50 mm
Nail length (min)	15 mm
Hose inner diameter	1/4 \
Maximum operating pressure	8.27 bar
Minimum operating pressure	4.82 bar
Power source	Pneumatic

Weight and Dimensions

Depth	70 mm
Width	250 mm
Height	256 mm
Weight	1300 g
