14
NOTE: The two fastening nuts (11) must be loosened before
tightening the V-belt or checking the tension.
To increase the belt tension, turn the tightening screw (12) to
the right (clockwise) with the combination wrench included with
the Power Cut.
The belt tension is correctly adjusted when the nut (13) is cen-
tred on the mark (14).
IMPORTANT:
After tightening/inspection, make certain to tighten
the fastening nuts (11) (30 ± 2 Nm).
Tightening the V-belt /
Checking V-belt tension
IMPORTANT
:
Exact V-belt tension is essential for maximum cutting per-
formance with minimum fuel consumption. Improper V-belt
tension will result in premature wear to the V-belt and V-belt
wheel or damage to the clutch bearing.
If the Power Cut is new or the V-belt has been replaced,
retighten the V-belt after the rst hour of operation!
Fuels
Caution:
This tool uses mineral-oil products (gasoline and oil).
Be especially careful when handling gasoline.
Do not smoke. Keep tool well away from open ames, spark,
or re(explosionhazard).
Fuel mixture
This tool is powered by a high-performance air-cooled two-stroke
engine. It runs on a mixture of gasoline and two-stroke engine
oil.
The engine is designed for unleaded regular gasoline with a
min. octane value of 91 ROZ. In case no such fuel is available,
you can use fuel with a higher octane value. This will not affect
the engine.
In order to obtain an optimum engine output and to protect
your health and the environment use unleaded fuel only.
To lubricate the engine, use a synthetic oil for two-stroke air-
cooled engines (quality grade JASO FC or ISO EGD), which
has to be added to the fuel. The engine is designed for the use
of MAKITA high-performance two-stroke engine oil at a mixture
ratio of only 50:1 to protect the environment. In addition, this
ensures a long service life and reliable operation with minimum
exhaust emissions.
Gasoline
50:1
50:1
+
The correct mixture ratio:
50:1 when using MAKITA high-performance two-stroke
engine oil, i. e. mix 50 parts gasoline with 1 part
oil.
50:1 When using other synthetic two-stroke engine
oils (quality grade JASO FC or ISO EGD), i. e.
mix 50 parts gasoline with 1 part oil.
OIL
50:1
1000 ml (1 litre) 20 ml 20 ml
5000 ml (5 litre) 100 ml 100 ml
10000 ml (10 litre) 200 ml 200 ml

Makita EK7301 Specifications

General

Blade bore	25.4 mm
Blade diameter	350 mm
Idle speed (max)	4300 RPM
Sound power level	109 dB
Cutting depth (90º)	122 mm
Sound pressure level	99.6 dB
Engine type	2-stroke engine
Engine power	5.2 hp
Fuel tank capacity	1.1 L
Vibration emission	7 m/s²
Engine displacement	73 cm³
Motor power	5.1 hp
Power source	Gasoline
Motor rated power	3.8 kW
Torque (max)	4.3 N⋅m
Maximum speed	80 m/s
Product color	Black, Blue
Mix ratio (fuel:oil)	50:1
Anti-vibration system	Yes
Engine number of strokes	2
Air filtration stages quantity	5

Weight and Dimensions

Depth	770 mm
Width	290 mm
Height	370 mm
Weight	10000 g
