Makita EK7301 User Manual

26
Press the cutting attachment (13) onto the drive arm in the
side position.
Guide the V-belt (14) over the V-belt pulley (15).
NOTE: The illustration shows the V-belt for models EK7300,
EK7301.
Put the guard plate (16) on.
Screw on nuts (17) and tighten by hand.
To tighten the V-belt see ”Tightening the V-belt / Checking V-
belt tension”.
Screw in and tighten the screw (detail X, only for EK8100).
Tighten the nuts (17)rmlywiththecombinationwrench.
Replace the grip (18) as shown.
IMPORTANT:
When you reposition the cutting attachment, the direction
of rotation of the cutting wheel changes.
If a rotation direction is marked on the cutting disc, make
sure the disc turns in the right direction.
Replacing/cleaning the spark arrester screen
Caution: Do not use sharp or pointed objects for screen
cleaning. Damaged or misformed screen wires may re-
sult.
Let cool the engine down for sure!
The spark arrester screen should be checked and cleaned
regulary. Replace spark arrester screen when needed.
Loosen the screw (25) and remove the spark arrester screen (26).
Reassembly the spark arrester screen and tighten the screw.
25
26
13 1415
16
17
18

Makita EK7301 Specifications

General

Blade bore	25.4 mm
Blade diameter	350 mm
Idle speed (max)	4300 RPM
Sound power level	109 dB
Cutting depth (90º)	122 mm
Sound pressure level	99.6 dB
Engine type	2-stroke engine
Engine power	5.2 hp
Fuel tank capacity	1.1 L
Vibration emission	7 m/s²
Engine displacement	73 cm³
Motor power	5.1 hp
Power source	Gasoline
Motor rated power	3.8 kW
Torque (max)	4.3 N⋅m
Maximum speed	80 m/s
Product color	Black, Blue
Mix ratio (fuel:oil)	50:1
Anti-vibration system	Yes
Engine number of strokes	2
Air filtration stages quantity	5

Weight and Dimensions

Depth	770 mm
Width	290 mm
Height	370 mm
Weight	10000 g
