Makita EK7301 User Manual

18
Adjusting
the carburetor
NOTE: The grinding parts are equipped with an electronic
ignition to limit the speed.
At the factory the idling speed has been set to approx.
2500 rpm, but the running-in process of a new engine may
require slight readjustment of the idling speed.
Adjustments to the adjusting screws (L) and (H) may only
be made by an authorised MAKITA service centre. Accor-
dingly, the holes for the two screws are sealed shut.
For correct adjustment of the idling speed the following
steps must be carried out:
Start the engine and run it until it is warm (about 3 - 5
minutes).
Adjust the carburetor with the screwdriver (1, Order No. 944
340 001) included with the Power Cut. It has a lug that helps
with adjustment.
Readjust the idling speed.
If the cut-off disc is still turning when the engine is running,
unscrew the adjusting screw of the throttle valve (2) until the
cut-off disc is no longer turning. When the engine is left running
at idling speed, tighten the screw a little.
Switch off the engine

Makita EK7301 Specifications

General

Blade bore	25.4 mm
Blade diameter	350 mm
Idle speed (max)	4300 RPM
Sound power level	109 dB
Cutting depth (90º)	122 mm
Sound pressure level	99.6 dB
Engine type	2-stroke engine
Engine power	5.2 hp
Fuel tank capacity	1.1 L
Vibration emission	7 m/s²
Engine displacement	73 cm³
Motor power	5.1 hp
Power source	Gasoline
Motor rated power	3.8 kW
Torque (max)	4.3 N⋅m
Maximum speed	80 m/s
Product color	Black, Blue
Mix ratio (fuel:oil)	50:1
Anti-vibration system	Yes
Engine number of strokes	2
Air filtration stages quantity	5

Weight and Dimensions

Depth	770 mm
Width	290 mm
Height	370 mm
Weight	10000 g
