17
Stopping the engine
Push the combination switch (6) down to position .
Cold start (Choke)
Warm start
Engine off
6
5
8
9
6
Cold starting:
GraspfronthandlermlywithonehandandpressthePower
Cut against the ground.
Place left toe in the rear handguard.
Push the combination switch (6) up (choke position). This will
automatically activate the half-throttle lock.
NOTE: If the Power Cut is mounted on the trolley, do not
operate the gas lever (throttle) on the side of the trolley!
Pull the starter cable out slowly until you feel resistance (piston
is now just before top dead center).
Press in the decompression valve (5).
Pull starter cable quickly and rmly, until you hear the rst
ignition, but to a max. of 3-5 pulls!
Important: Do not pull the starter cable out more than about
50 cm / 20”, and guide it back slowly by hand (instead of letting
it snap back).
Press in the decompression valve (5).
Move the combination switch (6) to the middle “I” position.
Againpullthestartercablequicklyandrmly.
As soon as the engine is running, grasp the rear handle (the
safety lock switch (8) will be depressed by the palm of your hand)
and tap the throttle (9). The half-throttle lock will be disengaged
and the engine will run in idle.
Warm starting:
As described above for cold starting, but before starting push
the combination switch (6) up (Choke position) and then right
away back to the middle “I” position.
Thisisonlytoengagethehalf-throttlelock.Iftheenginedoesn’t
start after 2 or 3 pulls, repeat the entire starting procedure as
described for cold starting.
Do not leave switch (6) in the choke position when hot
starting!
