Makita HR4013C Technical Information

Color index of lead wires' sheath
Black
Connector
Connector
Power supply cord
White
Red
Fig. D-1
Controller
Terminal block
with Line filters
Circuit diagram
Blue
Switch
Dial
Brown lead wire is used
for some countries.
Blue lead wire is used
for some countries.
Switch unit
P 17/ 19

Makita HR4013C Specifications

General

Chuck type	SDS Max
Product color	Black, Blue
Adjustable speed	Yes
Cord length	4 m
Input power	1100 W
Power source	AC
AC input voltage	110-240 V
Impact rate	2900 bpm
Rated speed (max)	500 RPM
Impact energy (max)	8.3 J
Sound pressure level	92 dB
Drilling diameter in steel (max)	- mm
Drilling diameter in concrete (max)	40 mm

Weight and Dimensions

Depth	479 mm
Width	112 mm
Height	263 mm
Weight	6800 g
