Makita LW1401 Technical Information

5-2 LUBRICANT AND ADHESIVE APPLICATION
Apply the following lubricants to protect parts and product from unusual abrasion.
Outer
periphery of
pipe 20-128
(77)
Apply 25g of Makita grease FA No.2 to Gear
section.
Apply Makita grease FA No.2.
Outer periphery of Sleeve 20 (112)
Safety cover (17)
Apply Makita grease FA No. 2 to fill the gap between
Safety cover (17) and Ring 17 (14) for dust-proof.
On the outer periphery of O ring 7 (114)
attached Stopper pin (only LW400)
Ring 17 (14)
Makita Corporation 4 / 15

Makita LW1401 Specifications

General

No Load Speed	3, 800 RPM
Amperage	15 A
Voltage	120 V
Blade Diameter	14 in
Cutting Capacity (Round)	127 mm
Arbor Size	1 in
Max Cutting Depth at 90°	127 mm
