Relling the oil tank
Only if the motor is switched off and the power supply plug
is pulled out!
- Thoroughly clean the oil tank around the cap to prevent dirt
from entering the tank.
- Unscrew the tank cap (
1)andllinchainoiluntilitisona
levelwiththebottomedgeofthellersocket.
- Tightly screw on the tank cap.
- Thoroughlyremoveanyoilthathasoverown.
Important!
Beforeoperatingthesawforthersttime,theoilfeedsystem
mustbecompletelylled,untilthechainoillubricatesthechain
and guide bar.
This procedure can take up to two minutes.
- The oil level can be controlled in the sight glass (
2).
Inordertoensuresufcientlubricationofthesawchainthere
must always be enough oil in the tank.
1
D
4
3
Lubricating the saw chain
Only if the motor is switched off and the power supply plug
is pulled out!
To guarantee a troublefree operation of the oil pump the oil guide
groove (3) as well as the oil inlet bore in the guide bar (4) must
be cleaned in regular intervals.
Note:
After the saw has been turned off it is normal for residual chain
oil to drip from the oil feed system, the guide bar and the chain
for a time. This does not constitute a defect!
Place the saw on a suitable surface.
Chain oil lter
Dirtparticlesthataccumulateonthechainoillterwillimpede
theowofchainoil.Thiswilleventuallyleadtopoorlubrication,
and faster wear to the chain and guide bar.
If the chain is no longer getting enough lubrication, the chain
oillter(6) will need to be cleaned or replaced.
- Remove the sprocket guard, chain, and guide bar (see
PUTTING INTO OPERATION).
- Carefully clean the area around the oil outlet hole (
5).
- Using a small screwdriver, carefully remove the serrated
washer (7)andchainoillter(6).
- Cleanthechainoillter.Ifitisseverelycontaminated,replace
it.
- Plug in the chain saw and let it run until the chain oil comes
out the oil outlet hole.
-
Switch off the saw and unplug the power cord.
- Clean the area around the oil outlet hole (
5) with a cloth.
- Insertthechainoillter(
6) and serrated washer (7) as shown
in Installation.Whentheoilltercannotbesecuredwith
the serrated washer, replace the serrated washer with a new
one.
- Put the guide bar, chain, and sprocket guard back on (see
PUTTING INTO OPERATION).
6
5
7
