Files and how to work with them

- Sharpenusingaspecialleholderwithasawchainround

ledia.4.0mm.Normalroundlesarenotappropriatefor

this work. See "Accessories" for the order number.

- Theleshouldcutonlywhenpushedforwards(arrow).Lift

thelewhenleadingitbackwards.

- First sharpen the shortest cutter. The length of this cutter is

then the standerd for all other cutters of the chain.

- Alwaysguidetheleasing.shown

- Theleholdermakesleguidanceeasier.Itismarkedfor

the correct 30° sharpening angle (keep the marks parallel

withthechainwhenling,seeillustration)andlimitsthecut

depthtothecorrect4/5ofthelediameter.See"Acces-

sories" for the order number.

- After having sharpened the chain, the height of the depth

limiter must be checked by means of a chain gauge. See

"Accessories" for the order number.

- Correcteventhesmallestexcessheightwithaspecialat

le(

1). See "Accessories" for the order number.

- Round off the front of the depth limiter (

2).

4/5

1 2

Cleaning the guide bar,

lubricating the sprocket nose

CAUTION: Protective gloves must be worn.

Regularly inspect the bearing surfaces of the guide bar for

damage, and clean them with a suitable tool.

If the saw is used intensively it will be necessary to lubricate the

returnsprocketbearingsregularly(onceaweek).Todothis,rst

thoroughly clean the 2 mm hole at the tip of the guide bar, and

then press in a small amount of multi-purpose grease.

Multi-purpose grease and grease guns are available as acces-

sories.

Multi-purpose grease (order no. 944 360 000)

Grease gun (order no. 944 350 000)
