Special tools
129
Fig. no. Designation Item number
19 Sleeves for valve stem seal
19.1 Insert sleeve for valve stem seal 80.99616–0004
19.2 Pressing sleeve for valve stem seal 80.99604–0005
20 Pressing tool for valve guide
20.1 Pressing mandrel for valve guide 80.99617–0013
20.2 Pressing rings in conjunction with 20.1 80.99616–0003
21 Piston ring tightener 80.99613–0035
22 Piston ring tightening sleeve 80.99604–0134
23 Tightening angle gauge 80.99605–0010
24 Piston ring pliers 83.09144–6090
25 Cylinder liner extractor device 80.99602–0019
25.1 Support for 25 80.99623–0003
25.2 Extractor plate 83.09143–0195
26 Cooling system test unit 80.99607–0061
27 Thread-cutting tool
27.1 Thread drill set, M15 x 2, for cylinder head bolt threads 80.40001–0001
27.2 Associated die ring 80.43001–0001
