Draining and filling with coolant
37
Draining coolant
Drain coolant as follows when the engine is cold:
Caution:
Risk of scalding if hot coolant is
drained! Drain coolant into a container
and dispose of it in accordance with
local regulations
Fig. 1
Remove cap (arrow) from filler neck on the coolant
expansion tank. Open drain plugs.
Fig. 2
Open drain plug in the oil cooler housing.
Use a container to catch coolant that may emerge.
Fig. 3
Further drain plugs for draining the coolant are lo-
cated on the exhaust-gas collector pipe (picture)
and on the intercooler.
3412
3413
3414
