Manitou 78 SEC 2 User Manual

2-8
CHARACTERISTICS 78 SEC
SPECIFICATIONS
-Use Indoor and outdoor
- Maximum capacity with capacity indicator
227 Kg (1)
113 Kg (2)
114 Kg (3)
- Number of people in the basket in indoor use
2 (1)
1 (2)
1 (3)
- Number of people in the basket in outdoor use
1 (1)
1 (2) (3)
- Number of steered wheels: Front / Rear 2 / 0
- Number of drive wheels: Front / Rear 2 / 0
- Operating speed 0,8 Km/h
- Transport speed 4 Km/h
- Working height (in working position) 7,6 m
- Floor height (in working position) 5,8 m
- Mass of the lifting platform
Unladen 1503 Kg
Under maximum nominal load 1730 Kg
- Number of gears 2
- Traversable slope (maximum load) 25 % - 14°
- Ground clearance (transport position) 6,1 cm
- Ground clearance (working position) 1,9 cm
- Max permissible wind speed 12,5 m/s
- Maximum authorised tilt (longitudinal) 3° - 5%
- Maximum authorised tilt (lateral) 1,5°
- Maximum permissible manual horizontal force indoors 400 N
- Maximum permissible manual horizontal force outdoors 200 N
- Sound level at ground controls level < 70 dBa
- Sound level at Lifting Platform controls level < 70 dBa
TYRES FRONT & REAR
- Dimensions 30 x 11 x 20 cm
- Pressure Foam
- Under maximum load on 1 wheel (front / rear) 600 Kg - 1323 Lbs
- Tyre contact pressure 10,35 Kg/cm² - 1014 kPa
- Pressure on ground 1313 Kg/m² - 12,88 kPa
LEVEL OF VIBRATIONS
- The vibrations received by the arm/hand and the complete body do not exceed 2,5 m/s²
- Quadratic average values for the body < 0,5 m/s²
(1) (3)(2)
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
