2-9
CHARACTERISTICS 100 SEC
SPECIFICATIONS
-Use Indoor
- Maximum capacity with capacity indicator
227 Kg (1)
113 Kg (2)
114 Kg (3)
- Number of people in the basket in indoor use
2 (1)
1 (2)
1 (3)
- Number of people in the basket in outdoor use 0 (1) (2) (3)
- Number of steered wheels: Front / Rear 2 / 0
- Number of drive wheels: Front / Rear 2 / 0
- Operating speed 0,8 Km/h
- Transport speed 3,5 Km/h
- Working height (in working position) 9,8 m
- Floor height (in working position) 7,92 m
- Mass of the lifting platform
Unladen 1959 Kg
Under maximum nominal load 2186 Kg
- Number of gears 2
- Traversable slope (maximum load) 25 % - 14°
- Ground clearance (transport position) 8,9 cm
- Ground clearance (working position) 2,2 cm
- Max permissible wind speed 0 m/s
- Maximum authorised tilt (longitudinal) 3° - 5%
- Maximum authorised tilt (lateral) 1,5°
- Maximum permissible manual horizontal force indoors 400 N
- Maximum permissible manual horizontal force outdoors 0
- Sound level at ground controls level < 70 dBa
- Sound level at Lifting Platform controls level < 70 dBa
TYRES FRONT & REAR
- Dimensions 38 x 13 x 28 cm
- Pressure Foam
- Under maximum load on 1 wheel (front / rear) 830 Kg - 1830 Lbs
- Tyre contact pressure 12,87 Kg/cm² - 1262 kPa
- Pressure on ground 1187 Kg/m² - 11,65 kPa
LEVEL OF VIBRATIONS
- The vibrations received by the arm/hand and the complete body do not exceed 2,5 m/s²
- Quadratic average values for the body < 0,5 m/s²
(1)
(3)(2)
647369 (01/03/2017) 78/100 SEC 2 / 120 SE 2
