999 LUFFING JIB OPERATOR MANUAL MAINTENANCE
6
BOOM AND LUFFING JIB ANGLE
INDICATOR CALIBRATION
The angle indicator potentiometers are located inside the
node controllers mounted on the boom top and on the luffing
jib top (Figure 6-2
).
The boom and luffing jib angles are calibrated automatically
by the crane’s programmable controller as part of the load
indicator calibration procedure (see separate Rated Capacity
Indicator/Limiter Operation Manual for instructions).
Typical Node Controller Installation
on Boom or Luffing Jib Top
Potentiometer Mounted
Inside
P1518
FIGURE 6-2
