1.4.4 Track-only xture on conservatory rafters
Fixture type 33
84
208
37
105
110
H
187
21
min. 100
max. 1000
A
A
C
min. 300
max. 400
C
30
15
30
105
R7,50
125
60 116
MA
BA
M
A-A
76735.
50
dimensions in mm
M = overall awning width
MA = awning xture width = order witdth = M minus 100 mm
A-A = in cross section
FW = width between xing points
H = projection
76735. = track bracket assembly for track xture directly on the
conservatory rafter
C = detailed drawing
from a xture width (MA) of 601 cm an cassette support assembly,
76183., is required
1.4.5 Reveal xture
Fixture type 16
76077.
76078.
(76180.)
BA
37
105
84
A
116
MA
76054.
A-A
M
76046.
25
B
min. 100
max. 1000
A
76054.
208
187 21
210
H
60
B
M = overall awning width
MA = awning xture width = order witdth = M minus 100 mm
A-A = in cross section
FW = width between xing points
H = projection
B = detailed view
76077. = bottom xture left reveal
76078. = bottom xture right reveal
76180. = coupled cassette bracket for bottom xture
76046. = track bracket with adjustable head 100 mm
76054. = universal track bracket assembly height 100 mm
from a xture width (MA) of 601 cm an cassette support assembly,
76183., is required
dimensions in mm
