M = overall awning width
H = projection
FW = width between xing points
MA = xture width = awning width between xture points
S = cross section
1 = cassettebottom xture bracket
2 = track bracket with adjustable head
3 = from an extension (H) of 401 cm an additional track bracket with
adjustable head is required
4 = from a xture width (MA) of 601 cm an cassette support assembly,
76183., is required
1.4 Dimension overviews and xture dimensions
1.4.1 Bottom xture
Overview of dimensions, see chapter 1.3.1 - 1.3.3. Respective information on the mounting dimensions of other
mounting types (see chapter 1.1) can be found in our sales documentation.
Overview of dimensions markilux 8800 / 8800 tracx
0
+
0$ %$
208
21
105
70
116
37
84
210
H
min. 100
max. 1000
30
MA
BA
60
50
187
M
76061.
76062.
(76180.)
76017.
A
A
S A-A
Fixture type 11
5 = cover support tube (the required quantity can be found in the size
grid in our sales documentation)
6 = from a xture width of (MA) 451 cm an additional support bracket (or
adjustable support bracket) for awnings with cover support tube is
required
76061. = bottom xture bracket assembly, rigid, left
76062. = bottom xture bracket assembly, rigid, right
76180. = cassette coupling bracket assembly
76017. = track bracket for track-only xture, rigid
measurements in mm
