Specifications
102
410/420/430 - 001 8903 U1
UZEL
Tractor specifications
Engine:
Make Perkins diesel to Massey Ferguson specification.
Type Four stroke, water cooled, direct injection.
Tractor Models applicable:
410 1103C-33 - Naturally Aspirated - (low emission engine).
420/430 1103C-33T - Turbocharged - (low emission engine).
Cylinders 3
Stroke 127 mm (5 in).
Bore 105 mm (4.134 in).
Engine capacity 3.3 liter (201 cu in).
Firing order 1, 2, 3.
Engine and PTO power and torque Consult the sales promotional leaflet for your model
of tractor issued by your local Massey Ferguson
Dealer at time of sale - Manufacturer's estimate.
Idle speed 750 rpm.
Maximum rated speed 2200 rpm.
Maximum no load speed 2470 rpm.
Maximum torque at 1400 rpm (MF 410) 222 Nm
Maximum torque at 1400 rpm (MF 420) 270 Nm
Maximum torque at 1400 rpm (MF 430) 291 Nm
Lubrication Throw-away canister type full flow external filter.
Valves Overhead, push rod operated.
Valve tip clearance:
Inlet 0,20 mm (0.008 in) Cold.
Exhaust 0,45 mm (0.018 in) Cold.
Cooling System:
Type Thermostat controlled with centrifugal pump to assist
circulation.
Gear driven centrifugal water pump .
Radiator pressure cap rating 1 bar (13.3 psi).
Fan belt(s) deflection 10 mm (3/8 in).
Fuel System:
Fuel lift pump Electrically driven.
Injection timing (static BTDC):
410/420/430 Sealed and not adjustable.
Injectors Delphi nozzles and holders.
Injector settings (working pressure):
410/420/430 300 bar (4350 psi).
Clamp & nut 30 Nm (23 lbf ft).
High pressure pipe nuts 22 Nm (16 lbf ft).
Leak-off pipe nuts 9,5 Nm (7 lbf ft).
Starting aid Glow plugs
Air System
Air cleaner Two-stage dry element with warning light. Removable
main and safety element.
Clutch
Type Dual or split torque (with cerametalic lining).
Size - main clutch 305 mm (12 in).
PTO clutch (dual clutch) 254 mm (10 in).
Pedal clearance 11 mm (7/16 in).
PTO clutch clearance 1,8 mm (0.070 in).
