Specifications
410/420/430 - 001 8903 U1
UZEL
103
Transmission
Gearbox types:
Eight-speed gearbox The eight-speed gearbox, standard or synchromesh,
has eight forward and two reverse speeds. This is
achieved by using a four forward and one reverse
speed gearbox, compounded by an epicyclic unit.
Eight-speed shuttle gearbox The eight-speed synchromesh shuttle gearbox has
eight forward and eight reverse speeds. The forward
and reverse (shuttle) selection being controlled by a
lever on the instrument panel adjacent to the steering
wheell.
Gearbox constant mesh gear ratio:
All models 2.7368:1.
Creep gearbox (if fitted )
Reduction in all gears 4:1
Rear axle
410/420/430 Planety drive.
Type Normal duty.
Crown wheel and pinion ratio:
410/420/430 5.1428:1 - 7 x 37
Maximum permissible load capacity:
All models 3628 kg (7982 lb).
Rear track settings (all at 102 mm (4 in) increments):
Pressed steel wheels:
410/420/430 1220 mm (48 in) to 1930 mm (76 in).
Foot brakes -
410/420/430 planetary drive Oil immersed mechanical operation, planetary drive
Parking brake Operates on both rear wheels at the same time
independent of the foot brakes.
Power take-off (PTO):
Live PTO / Independent PTO (IPTO) Engaged by a lever on the left of the center housing.
PTO Speed - 410 540 rpm at 1685 engine rpm.
IPTO Speed - 420/430 540 rpm at 1789 engine rpm.
Shaft Diameter 35 mm (1 3/8 in).
No. of splines 6.
Engine to PTO shaft ratio:
MF 410 3.1176:1
MF 420/430 3.3125:1
Steering:
410/420/430 Hydrostatic power steering.
Pump Tandem.
Toe-in - two-wheel drive axle 0 to 5 mm (0 to 3/16 in).
Toe-in - four-wheel drive axle 0 to 5 mm (0 to 3/16 in).
Steering wheel Fixed.
Turning circles:
2WD 6500 mm .
4WD 7000 mm .
