X2
Page 2-4 2014 MasterCraft Owners Manual • Guide to Individual Models
G U I D E T O I N D I V I D U A L M O D E L S
Length of Boat .............................20’
Width Amidship ..........................96”
Boat Weight .......3,350-3,500 lbs.
Length of Boat w/Platform .. 22’1”
Towing Length ........................ 22’9”
Towing Width ............................ 100”
Fuel Capacity ................. 42 gallons
Maximum Capacity .........................
................. 11 people or 1,446 lbs.
............... Bow: 4 people or 600 lbs.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, port and starboard sun pads.
1 = Bow cleat
2 = Ballast tank (beneath oorboard)
3 = Bilge thru-hull outlet
4 = Ballast thru-hull vent
5 = Adjustable mirror
6 = Nav/anchor light
7 = Stereo remote (on dash)
8 = Amp (below)
9 = Circuit breaker panel (on kick panel beneath
instrument panel)
10 = Instrument panel (details in Video Display
Gauge section)
11 = Steering wheel
12 = Shift/throttle control
13 = Heated seat (where equipped)
14 = Fire suppression unit manual override
15 = Subwoofer
16 = Auto re extinguisher
17 = Engine compartment
18 = Bilge thru-hull vent
19 = Stern cleat
20 = Nav/anchor light (if equipped with tower,
the light will be in center aft of tower)
21 = Shower wand & switch (where equipped,
inside compartment)
22 = Transom stereo remote (where equipped)
23 = Underwater lights (two, where equipped)
24 = Transom rail with tow eye
25 = Attitude adjustment plate (where equipped)
26 = Transom drain plug
27 = Engine exhaust
28 = Surf tabs (on both sides, where equipped)
29 = Stern cleat
30 = Fuel tank ller
31 = Ballast thru-hull vent
32 = Ski pylon
33 = Batteries ON-OFF switch (under seat)
34= Cockpit table mount (where equipped)
35 = Cooler (under seat)
36 = Center drain plug (under inspection plate)
37 = Heated observer seat (where equipped)
38 = Hand-held re extinguisher (beneath
observer seat)
39 = Amp (where equipped)
40 = Batteries (under seat)
41 = Nav/anchor light
42 = Glove box
43 = Walk-thru seat (where equipped)
44 = Bow ller cushion (where equipped)
45 = Bow cleat
