XSTAR
Page 2-18 2014 MasterCraft Owners Manual • Guide to Individual Models
G U I D E T O I N D I V I D U A L M O D E L S
Length of Boat ............................. 24’
Width Amidship ........................ 102”
Boat Weight ....................5,500 lbs.
Length of Boat w/Platform .. 26’1”
Towing Length .........................29’4”
Towing Width ............................ 102”
Fuel Capacity ..................74 gallons
Maximum Capacity .........................
................ 13 people or 1,852 lbs.
................Bow: 5 people or 700 lbs.
Storage space is located under:
Observer’s seat, bow seating, aft and wrap-
around seating, and port and starboard sun pads.
1 = Anchor
2 = Ladder (where equipped)
3 = Bow cleat
4 = Horn
5 = KGB ballast tank (beneath oorboard)
6 = Adjustable mirror
7 = Circuit breaker panel (on kick panel beneath
instrument panel)
8 = Nav/anchor light
9 = Fuel tank ller
10 = Instrument panel (details in Video Display
Gauge section)
11 = Steering wheel
12 = Fire suppression unit manual override
13 = Midship cleat
14 = Shift/throttle control
15 = Heated seat (where equipped)
16 = Cooler (under seat)
17 = Stern light receptacle
18 = Engine compartment
19 = Stern cleat
20 = Ballast tank
21 = Automatic re extinguisher
22 = Freshwater ush port (where equipped)
23 = Shower (where equipped)
24 = Underwater lights (two, where equipped,
under swim platform)
25 = Under-platform ladder (where equipped)
26 = Swim platform
27 = Transom drain plug (center beneath
swim platform)
28 = Transom rail with tow eye
29 = Wake adjustment plate (under swim
platform, where equipped)
30 = Washdown connection (where equipped)
31 = Freshwater tank ll
32 = Stereo remote (where equipped)
33 = Blower exhaust (two, on top of port and
starboard deck near transom)
34 = Stern cleat
35 = Ballast tank
36 = Batteries (including ON-OFF switch)
37 = Subwoofer
38 = Center drain plug (access plate under lid)
39 = Jump seat
40 = Midship cleat
41 = Observer seat (heated, where equipped)
42 = Fuel tank ller
43 = Stereo remote (on dash)
44 = Nav/anchor light
45 = Glove box
46 = iPod interface (inside, where equipped)
47 = Hand-held re extinguisher (inside)
48 = Amp
49 = Bow ller cushion (where equipped)
50 = Bow cleat
