19
CHAPTER3: Part Replacement Guide
3.3 CUP HOLDER REPLACEMENT(E30&E50)
1) Confirm cup holder location. (Fig-1)
2) Remove the 3 screws from both sides. (Fig-2)
3) Remove the bad cup holder and install new cup holder.
4) Fasten the 4 screws.
Fig-1 Fig-2
