Matrix Retail E50 User Manual

22
CHAPTER 3: Part Replacement Guide
3.6 LINK ARM REPLACEMENT (E30/E50)
1) Open the side cover.
2) Remove the nut and bolt to remove the link arm from the handlebar -(Fig-1~ Fig-5 )
Fig-1 Fig -2
3) Remove the bolt securing the link arm to the swing arm.
4) Remove footplate if necessary.
5) Reverse order to install link arm.
Fig-3 Fig-4 Fig-5
