Matrix T50x-02 User Manual

53
8.3 Side rail removal
1. Remove the end cap as outlined in section 8.2
2. Remove the reinforce tube two screw using a
4mm Allen wrench (Figure A)
3. Slide the rail off the back of the treadmill
( Figure B )
Figure A
Figure B
