Matrix T50x-02 User Manual

55
8.5 Deck cushion replacement
1. Remove the deck as outlined in section 8.3
2. Holding the bolt with 5mm Allen wrench,
loosen the nut with 13mm socket
(Figure A and B)
3. For the rear cushion, hold the cushion and
remove the 13mm nut (Figure C)
Figure A
Figure B
Figure C
