Matrix T50x-02 User Manual

57
8.7 Running belt replacement
1. Remove shrouds as outlined in section 8.1
2. Remove rear roller as outlined in section 8.2
3. Remove front roller as outlined in section 8.5
4. Remove deck as outlined in section 8.4
5. Remove the running belt and replace with new
belt (Figure A and B)
6. *New running belts must ALWAYS be installed
to a new deck surface*
Figure A
Figure B
