24
1) To enter Service Mode, press "ENTER 3, 0, 0, 1, ENTER" on the number keypad and Service Mode will appear on the display.
2) Service Mode is divided into 4 tabs, located on the left side of the screen. They are Setup, Test, Log, and Date & Time.
3) Choose a tab by touching the screen over the desired tab.
4) Each of the tabs have options that will appear once you have chosen that particular tab.
5) Press the "HOME" button or the EMERGENCY STOP to exit Service Mode..
7.1 USING SERVICE MODE
FUNCTION & DEFAULTS DESCRIPTIONS MODIFIED
Machine Type
Default: Treadmill
This option is to select the current model. N/A
Serial Number This option displays the serial number of the console and frame. N/A
Accumulated Distance Total distance displayed in native units (miles or kilometers), not editable. N/A
Accumulated Time Total time, not editable. N/A
Show Service on Boot Factory Setting Only N/A
SERVICE MODE
Setup
7.2 SERVICE MODE - TAB 1
CHAPTER 7: SERVICE MODE
To Next Page
