Medion MD19601 User Manual

207
DE
FR
ES
NL
IT
EN
5.3. Bottom
7
8
9
10
11
12
13
14
15
16
17
19
20
21
18
7) Mounting pads for wiping cloth (on back)
8) Water tank filler opening with sealing cap
9) Water tank locking tabs
10) Dust container
11) Suction opening with brush
12) Right wheel: for driving the appliance
13) Type plate and battery compartment
14) Cleaning brush, right
15) Wheel: to aid the direction of movement
16) Charging contacts
17) Cleaning brush, left
18) Locking slot for the water tank
19) Left wheel: for driving the appliance
20) Brush frame
21) Retaining lugs for mop attachment
19601 ML DirectSales ML Content 5006 4564 RC1.indb 20719601 ML DirectSales ML Content 5006 4564 RC1.indb 207 24.09.2020 14:08:1624.09.2020 14:08:16

Medion MD19601 Specifications

General

Brand	Medion
Model	MD19601
Category	Vacuum Cleaner
Language	English
