Left display range
The display 1 shows the available power of the
drive system.
Under normal operating conditions, the display
1 is in the maximum range.
The power output available may deviate from the
maximum range in the event of:
R
very high or low outside temperatures
R
very high performance requirements for a
longer period of time
R
very low charge status of the high-voltage
battery
R
a malfunction in the drive system
The current charge level of the high-voltage bat‐
tery and the range are displayed in the lower
segment 2.
Setting the additional value range
Power display (example)
1
Additional value range
2
Index points
#
To select display content: swipe to the
right on the left-hand Touch Control.
#
Swipe upwards or downwards on the left-
hand Touch Control to select display content.
When display content is selected, the addi‐
tional value range 1 will briefly be highligh‐
ted.
The index points 2 will display the selected
list item.
The following content can be shown:
R
Range
R
ECO display
266
Instrument Display and on-board computer
