To open: pull cover 2 out by its top handle
edge.
#
Press in cigarette lighter 1.
The cigarette lighter will pop out automati‐
cally when the heating element is red-hot.
Sockets
Using the 12 V socket in the front center
console
Requirements:
R
Only devices up to a maximum of 180 W
(15 A) are permissible.
#
Lift up socket cap 1.
#
Insert the plug of the device.
If you have connected a device to the 12 V
socket, leave the cover of the stowage compart‐
ment open.
Using the 12 V socket in the rear passenger
compartment
Requirements:
R
Only connect devices up to a maximum of
180 W (15 A).
#
Pull cover 2 out by its top handle edge.
#
Remove plug 1 from the socket and insert
the plug of the device.
Using the 115 V socket in the cargo compart‐
ment
&
DANGER Risk of fatal injury due to dam‐
aged connecting cables or sockets
If a suitable device is connected, the 115 V
socket will be carrying a high voltage. If the
connecting cable or the 115 V socket is
pulled out of the trim or is damaged or wet,
you could receive an electric shock.
Seats and stowing
107
