MAINTENANCE
eng 103
Assemble steering link rod to engine with bolt, locknut, spacer,
and flat washers. Torque locknut to specifications.
a - Bolt (10‑898101018)
b - Flat washer (12‑95392‑10)
c - Spacer (23‑853826001)
d - Nylon insert locknut (11‑16147‑‑3)
e - Install steering link rod into side hole
f - Nylon insert locknut (11‑16147‑‑3) (tighten until it seats,
then back off 1/4 turn)
Description Nm lb. in. lb. ft.
Nylon insert locknut "d" 27 20
Nylon insert locknut "f"
Tighten until it seats, then back off ¼
turn
Corrosion Control Anode
Your outboard has corrosion control anodes at different
locations. An anode helps protect the outboard against galvanic
corrosion by sacrificing its metal to be slowly corroded instead of
the outboard metals.
a
b
c
b
d
e
b
f
9691
