1 CCM-270A/WS
201807 95
8.2 Group
Tap at the lower-left corner to go to the group editor from the installation page.
This shows the groups already created by the user: clicking on “+” will show the subgroups present under that
group. Similarly clicking on “-” will hide the groups present in that particular group. Clicking on the name of the
group will show the indoor units present in that group in 2. The bracket besides the name of the group shows the
number of units present in that particular group
This shows the subgroups present under a group and also the units that do not belong to any subgroup but belong
to the group selected. The bracket along the name of each subgroup tells the name of units under that subgroup.
Click on a unit to select it and click on “Delete” to delete that particular indoor unit from that group.
This provides the option to sort the indoor units by name or by mode.
This complete part shows the indoor units that do not belong to any of the groups. Click on the unit to select it and
click on “Add” to add that unit to the current indoor unit group.
This displays the code of the outdoor/indoor unit. The details about the code of the unit have been given in the
“Control” part of this manual.
Group creation is on the Left.
When a group is selected, the group and the indoor units in that group are shown in the middle. Indoor units that have not
been grouped are shown on the left
