Miele DA 2270 User Manual

Changing a halogen lamp
Before any cleaning or maintenance
work is carried out, disconnect the
cooker hood from the mains supply.
^
Remove the grease filter.
^
Remove the charcoal filters if the
cooker hood is being used in
recirculation mode.
,
Exercise caution when changing
halogen lamps. They get very hot
during use, and remain hot for some
time after being switched off.
Do not touch the surface directly
when changing a lamp, as grease
particles from your fingers will
adhere to the surface and damage
it. Please follow the manufacturer's
instructions.
^ Push down the lighting unit slightly
via the opening in the safety panel.
^ The halogen lamp is now accessible
and should be unscrewed
anti-clockwise.
^ Replace it with a new halogen lamp
(specification: GU/GZ 10, 230 V,
50 W). Screw the lamp into the
socket and push it upwards.
Please follow the manufacturer's
instructions.
We recommend only using lamps of the
same specification and also made by
the same manufacturer as the ones
being replaced.
^
Replace the grease filter and, if being
used in recirculation mode, the
charcoal filters.
Cleaning and care
24

Miele DA 2270 Specifications

General

Noise level	40 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Maximum extraction power	640 m³/h
Minimal distance from hob	45 cm
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Number of filters	2 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power consumption (typical)	300 W
Power requirements	230V, 50Hz, 10A

Weight and Dimensions

Depth	400 mm
Width	700 mm
Height	285 mm
Weight	9500 g
