Miele DA 2270 User Manual

Electrical connection
^
If the cooker hood is to be connected
to an external motor (EXT models):
Use the connection cable with 6 pole
plug to connect the cooker hood and
the external motor.
^ Connect the appliance to the mains
via a fused spur or fused socket as
appropriate.
Before connecting the appliance
read the safety notes in "Warning
and Safety instructions" and
"Electrical connection".
Installation
32

Miele DA 2270 Specifications

General

Noise level	40 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Maximum extraction power	640 m³/h
Minimal distance from hob	45 cm
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Number of filters	2 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power consumption (typical)	300 W
Power requirements	230V, 50Hz, 10A

Weight and Dimensions

Depth	400 mm
Width	700 mm
Height	285 mm
Weight	9500 g
