Fitting the non-return flap
(not needed for recirculation mode)
^ If a non-return flap is not present in
the venting system, the non-return
flap supplied must be fitted onto the
exhaust socket in the motor unit. The
flaps must open upwards.
DA 2250, DA 2270: 1 non-return flap
DA 2210: 2 non-return flaps
Building in
The cooker hood is designed for
installation in wall units, cooker hood
housing units, and above breakfast
bars or island areas.
Check prior to installation that the top of
the appliance will be accessible after
installation.
If this is not the case, install the exhaust
ducting and prepare the electrical
connection before installation.
^
Place the appliance in the cut-out
from below and align it.
^ Secure the cooker hood by the frame
using 3.5 x 16 mm screws.
^
Before using the appliance for the
first time, take the grease filters out
and remove the protective foil from
the filter frame. Then replace the
grease filters.
Installation
28

Miele DA 2270 Specifications

General

Noise level	40 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Maximum extraction power	640 m³/h
Minimal distance from hob	45 cm
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Number of filters	2 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power consumption (typical)	300 W
Power requirements	230V, 50Hz, 10A

Weight and Dimensions

Depth	400 mm
Width	700 mm
Height	285 mm
Weight	9500 g
