The Miele DSM 400 control module can
be used to combine the cooker hood
with other components.
It enables the following:
Potential free connection
This can be used to operate a further
appliance via the On/Off button s on
the cooker hood.
The potential free contact on the
DSM 400 a can, for example, be used
in a cooker hood with an external motor
...EXT, which is connected to a central
ducting system.
The contact can then be used to
operate an electrically driven non-return
flap b which is connected to the
central extraction unit c.
Components used in the central
ducting system are not supplied by
Miele.
If in any doubt, the advice of a
competent builder or, for gas, a Gas
Safe installer must be sought.
Connection to a light switch
The control module can be used to
switch on the cooker hood lighting and
also to dim it, depending on model, via
a light switch in the house.
Installation
The control module is fitted onto the
cooker hood housing.
The electrical connection of
components to the control module
must be carried out by a suitably
qualified and competent person.
Operation with Control module DSM 400
37

Miele DA 2270 Specifications

General

Noise level	40 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Maximum extraction power	640 m³/h
Minimal distance from hob	45 cm
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Number of filters	2 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power consumption (typical)	300 W
Power requirements	230V, 50Hz, 10A

Weight and Dimensions

Depth	400 mm
Width	700 mm
Height	285 mm
Weight	9500 g
