Miele DA 2270 User Manual

Silencer
(optional accessory)
To achieve even further reductions in
noise levels, a special silencer can be
fitted in the ducting system.
...with air extraction:
The silencer not only reduces noise
from the fan, but also sounds from
outside (e.g. traffic noise).
For this reason the silencer must be
positioned as close as possible to where
the ducting leaves the building a.
...in recirculation mode:
The silencer needs to be positioned
between the fan and the exhaust grille
b. The space needs to be checked in
some cases.
...air extraction with external fan:
To minimise noise from the fan in the
kitchen, the silencer should be
positioned in front of the external fan c
if possible, or if the ducting is long, then
in the ducting inside the cooker hood
itself d.
In the case of an external fan placed
inside the house, fitting a silencer
behind the external fan e reduces the
noise of the fan outside the house.
In all modes of operation, the most
effective noise reductions are
achieved if two silencers are fitted in
the system.
Connection for air extraction
35

Miele DA 2270 Specifications

General

Noise level	40 dB
Intensive speed	Yes
Number of speeds	4
Type of extraction	Ducted/Recirculating
Maximum extraction power	640 m³/h
Minimal distance from hob	45 cm
Cord length	1.5 m
Control type	Buttons
Product color	Stainless steel
Number of filters	2 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)
Power consumption (typical)	300 W
Power requirements	230V, 50Hz, 10A

Weight and Dimensions

Depth	400 mm
Width	700 mm
Height	285 mm
Weight	9500 g
