Technical Information
31
G 1xxx/G 2xxx
Function Programming Display
Appliance height setting
1
Press the Program (or
Delay Start for G 2143)
button 36x. Press the
Start/Stop button as
appropriate to make the
desired setting.
The "Rinse & Hold" LED flashes 3x
slowly and 6x rapidly. "Rinse" LED
is off: Standard appliance height (G
1xxx); "Rinse" LED
flashes: XXL models (G 2xxx).
Model setting
1
Press the Program (or
Delay Start for G 2143)
button 38x. Press the
Start/Stop button as
appropriate to make the
desired setting.
The "Rinse & Hold" LED flashes 3x
slowly and 8x rapidly. "Rinse" LED
off: Models without drying fan;
"Rinse" LED flashes: Models
with UTT version 1 or 2: G x142,
G x143.
3
Country setting
1
Press the Program (or
Delay Start for G 2143)
button 39x. Press the
Start/Stop button as
appropriate to make the
desired setting.
The "Rinse & Hold" LED flashes 3x
slowly and 9x rapidly. The "Rinse"
LED’s flash pattern indicates which
country specification is set: 1x:
Europe; 2x: Australia; 3x: USA; 4x:
Japan; 5x: Italy/Spain; 6x: Southern
Europe.
4
Table 21: Service Programming Mode Summary, G 2142/G 2143
1
If the electronic needs to be replaced during servicing, the following steps must be taken
during programming: In the first step, set the country specification and model, then switch
off the appliance. Repeat access and then set appliance width and height, and the
appropriate supply water hardness.
2
If the dishwasher is connected to an external ion exchanger water softener (i.e. that
needs to be regenerated with salt), the water hardness delivered by the system must be
set. If this value is unknown, set to 8°d (8.6 grains per gallon).
3
Circulation Turbothermic drying (UTT) version 1 (with condenser), version 2 (without
condenser).
4
The SER country specification includes the following countries: Portugal, France, the
Netherlands, Belgium and Great Britain.
Save and quit:
Switch off the appliance.
Water Hardness [°d] Water Hardness [gpg]
Flash Pattern of "Rinse"
LED
1 – 4 1.1 – 4.3 1x rapidly
5 – 7 5.4 – 7.5 2x rapidly
8 – 11 8.6 – 11.8 3x rapidly
12 – 15 12.8 – 16.1 4x rapidly
1
16 – 20 17.1 – 21.4 5x rapidly
21 – 25 22.5 – 26.8 6x rapidly
26 – 30 27.8 – 32.1 7x rapidly
31 – 36 33.2 – 38.5 8x rapidly
37 – 50 39.6 – 53.5 9x rapidly
51 – 70 54.6 – 74.9 1x slowly
Table 22: Water Hardness Settings, G 2142/G 2143
1
Standard setting.
