Technical Information
37
Master Chef Ovens
5.8 Top Cover - Removal
1. Remove the Front Doors (Section 5.2)
2. Remove the oven (Section 5.5)
3. Remove the Control Panel (Section 5.6)
4. Remove the Safety Cover (Section 5.7)
5. Refer to Figure 5-5, Remove the Top Cover Side Retaining Screws
(Item 4) and the Top Cover Rear Retaining Screws (Item5)
6. Lift the cover from the oven.
5.9 Upper Back Panel (Double Ovens) - Removal
1. Remove the Front Doors (Section 5.2)
2. Remove the oven (Section 5.5)
3. Remove the Control Panel (Section 5.6)
4. Remove the Safety Cover (Section 5.7)
5. Remove the Top Cover (Section 5.8)
6. Remove the twelve Rear Retaining Screws.
7. Remove the two Side Retaining Screws.
8. Slide the panel down while pulling it from the oven.
5.10 Lower (or Single Oven) Back Panel - Removal
1. Remove the Front Doors (Section 5.2)
2. Remove the oven (Section 5.5)
3. Remove the eighteen Rear Retaining Screws.
4. Remove the two Side Retaining Screws.
5. Slide the panel upward while pulling it from the oven.
5.11 Upper (Double Oven) Side Covers - Removal
1. Remove the Front Doors (Section 5.2)
2. Remove the oven (Section 5.5)
3. Remove the Control Panel (Section 5.6)
4. Remove the Safety Cover (Section 5.7)
5. Remove the Top Cover (Section 5.8)
6. Remove the Upper Back Panel (Section 5.9)
7. Remove the Side Cover Retaining Screws.
8. Lift the panel from the oven.
