Miele H395BP User Manual

Technical Information
57
Master Chef Ovens
5.33 Door Hinge(s) - Removal
1. Remove the Front Door (Section 5.2).
2. Remove the Front Door Outer Glass Pane (Section 5.30).
3. Remove Hinge Fastening Screws (Figure 5-25 Item1
4. Remove the Hinge from the Door Frame.
5. Repeat for opposite side.
Figure 5-25: Door Hinge Removal

Miele H395BP Specifications

General

Fuel Type	Electric
Energy Efficiency Class	A
Installation Type	Built-in
Door Material	Glass
Timer	Yes
Child Lock	Yes
Type	Built-in
Cleaning System	Pyrolytic
Frequency	50 Hz
Dimensions (H x W x D)	595 x 594 x 548 mm
Width	59.5 cm
Height	59.6 cm
