Miele H395BP User Manual

Technical Information
45
Master Chef Ovens
Figure 5-13 Door Latch Assembly
6. Refer to Figure 5-13. Remove the two screws that secure the Latch
Assembly to the Cavity Assembly.
7. Slightly lift the Upper Housing near the front to access the Latch
Assembly, as shown in Figure 5-14.
Service Tip - Upper & Lower Door Close Switch Removal
To simplify access to the Door Switch Retaining Tabs, the Right Side
Panel can be removed permitting direct access to the underside of the
locking tabs.

Miele H395BP Specifications

General

Fuel Type	Electric
Energy Efficiency Class	A
Installation Type	Built-in
Door Material	Glass
Timer	Yes
Child Lock	Yes
Type	Built-in
Cleaning System	Pyrolytic
Frequency	50 Hz
Dimensions (H x W x D)	595 x 594 x 548 mm
Width	59.5 cm
Height	59.6 cm
