Technical Information
26
Master Chef Ovens
4.8 Automatic / Safety Shutdown
Each program has a maximum operation time. When the maximum
operation time is reached, the oven turns itself off.
Table 4-4: Automatic Safety Shutdown durations
4.9 Cavity Temperature Sensor (1R30 & 4R30)
The Oven Cavity Temperature Sensor is located in the guide tube of the
Upper Heating Elements (Figure 4-2, Item 1). The Sensor sends a signal
back to the Main Electronic. The oven cavity temperature is calculated
and displayed via the Display Electronic.
Figure 4-2: Upper Heater Element Cavity
Temperature Sensor
Program Time-Out (in hours)
Bake 12
Convection Bake 12
Top / Bottom Heat 12
Browning 12
Intensive 6
Auto Roast 12
Convection Roast 12
Top / Bottom Roast 12
Broil 6
Maxi Broil 6
Rotisserie 6
Convection Broil 6
Dehydration 24
Proof 24
Defrost 24
Self Clean N/A
Sabbath Baking 72
