Technical Information
54
Master Chef Ovens
5.30 Front Door, Outer Glass Pane - Removal
1. Handle Retaining Screws (2)
2. Spacer Brushings (2)
3. Handle
4. Door Frame
5. Retaining Screws
6. Outer Glass
Figure 5-22: Front Door, Outer Glass Pane Removal
1. Remove the Front Door. (Section 5.2)
2. Refer to Figure 22. Position the Front Door Glass Area (outer glass
facing down) on a flat work surface.
3. Remove the Handle Retaining Screws (Item 1).
4. Remove Handle (Item 3).
5. Remove the Outer Glass Pane Retaining Screws (Item 5).
6. Remove Outer Glass Pane (Item 6)
Note
When installing the outer glass pane, position the glass pane correctly
over the spacer brushings (Figure 5-22 Item 2).
